1. Open Revit and create a new family file by selecting "New" under the "Family" category.
2. Choose the "Mechanical Equipment" template from the list of available templates.
3. Name the family file and save it to your desired location.
4. The AHU family typically consists of a casing, filter, fan, coil, and duct connections. Add these components to your family by selecting the appropriate components from the "Mechanical Equipment" tab.
5. Adjust the size and position of each component to fit the dimensions of the AHU you are creating.
6. Configure the properties of each component such as airflow rate, static pressure, and filter efficiency.
7. Add any necessary annotations, parameters, and connectors to the family.
8. Save the family file and load it into your project.

Note that creating an AHU family can be a complex process and may require additional knowledge of HVAC systems and Revit software. It is recommended to consult resources such as Revit tutorials, forums, and documentation for further guidance.
